86-inch All-in-one Touch Panel Computer
1.86inch large size; 2. Dusal System: Android 11.0 with 4GB+32GB storage; 3.windos 10 system under OPS i5 11th generation, with 8GB+256GB 4. 1300W pixel camera, 8digital mics,
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
86-inch all-in-one touch panel computer LX-86-AH
PRODUCT FEATURES: |
l Equipped with Android 11.0 intelligent operating system and unique 4K UI design;
l Internal cache capacity 4GB + internal storage capacity 32G, the system runs faster;
l Infrared touch, Android system supports 20-point touch, Windows system supports 36-point touch, touch accuracy up to ±1mm, touch height 2.0mm,gh; 2mm, the display response speed ≤2ms, and the sensitivity is high;
l Support video, music, pictures, PPT and other multimedia teaching software;
l High-performance writing software, support single-point, multi-point writing, increase the pen writing effect, etc., annotation can be carried out under any channel and any interface;
l ≤4mm anti-glare AG tempered glass is used, and the hardness of tempered glass can reach Mohs 7, which is 1-9 hardness higher than graphite; Effectively reduce the reflection of light, haze 3%-8%, visible light transmittance 90% and above; (Optional).
l MULTI-SCREEN INTERACTION: SUPPORT MOBILE PHONES, IPADS, LAPTOPS AND OTHER EQUIPMENT PROJECTION. (Optional).
1.86inch large size;
2. Dusal System: Android 11.0 with 4GB+32GB storage;
3.windos 10 system under OPS i5 11th generation, with 8GB+256GB
4. 1300W pixel camera, 8digital mics,
Disclaimer: Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Unless otherwise agreed, all statements, information and recommendations in this document are intended as guidance for use only.
|
Specifications |
||
|
Product model |
LX-86-AH |
|
|
Product name |
86-inch all-in-one touch computer |
|
|
Display parameters |
The effective display area |
1895(H)× 1066(V)mm |
|
Display scale |
16：9 |
|
|
brightness |
350cd/m2 |
|
|
contrast |
4000：1 |
|
|
Display colors |
10bit,1.07B |
|
|
Backlight type |
DLED |
|
|
Viewing angle |
178° |
|
|
resolution |
3840(H)×2160(V) |
|
|
Parameters of the whole machine |
Video format |
PAL/NTSC/SECAM |
|
Accompaniment system |
DK/BG/I |
|
|
Accompanying sound output power |
2×15W |
|
|
Power consumption of the whole machine |
≤ 230W (without PC) |
|
|
Standby power consumption |
≤0.5W |
|
|
The life of the whole machine |
50,000 hours |
|
|
Enter the power supply |
100-240V, 50/60Hz |
|
|
The size of the whole machine |
1954.8 mm ×1157.2mm×76.6mm |
|
|
1954.8 mm × 1157.2mm×107mm (including hangers). |
||
|
Package size |
2110mm×1320mm×210mm |
|
|
net weight |
68KG |
|
|
gross weight |
74KG |
|
|
Working environment |
Operating temperature: 0°C ~ 50°C; Operating humidity: 10%RH ~ 80%RH |
|
|
Storage environment |
Storage temperature: -20°C ~ 60°C; Storage humidity: 10%RH ~ 90%RH |
|
|
port |
Front ports: USB*3, HDMI*1, TOUCH USB*1, TYPE-C*1 |
|
|
|
Rear ports: TOUCH-USB*1, RJ45*1, MiniAVin*1, HDMI*2, RS232*1, USB3.0*1, USB2.0*1, MiniAVout*1,Earphone*1 |
|
|
WIFI |
2.4+5G |
|
|
Bluetooth |
Optional |
|
|
Android system parameters |
CPU |
T982 Quad-core ARM Cortex-A55 |
|
GPU |
Mali-G52 MP2 |
|
|
RAM |
4G |
|
|
FLASH |
32G |
|
|
Android version |
Andriod 11.0 |
|
|
OSD language |
Chinese, English |
|
|
OPS parameters |
CPU |
I3/I5/I7 optional |
|
memory |
4G DDR4/ 8G DDR4 optional |
|
|
hard disk |
128G SSD/ 256G SSD optional |
|
|
operating system |
Windows 10 |
|
|
port |
HDMI*1,USB2.0*4,USB3.0*2,VGA*1,Earphone*1,MIC*1,RS232*1,RJ-45*1 |
|
|
WIFI |
Supports 802.11 b/g/n |
|
|
Touch Parameters |
Touch type |
Infrared touch |
|
Touchscreen sensing method |
Fingers, writing pens, or other opaque objects ≥ Ø6mm |
|
|
Touch resolution |
32767*32767 |
|
|
Communication port |
USB male type B |
|
|
Responsiveness |
≤8 ms |
|
|
Customized precision |
≤±2mm |
|
|
Multi-touch |
20 points of touch |
|
|
The number of touches |
Theory unlimited times |
|
|
The operating system is supported |
WIN7, WIN8, WIN10, LINUX, Android, MAC, domestic system |
|
|
Camera parameters (Optional) |
pixel |
1300W |
|
Image sensors |
1/3.06" CMOS |
|
|
lens |
Prime lens with an effective focal length of 2.1mm |
|
|
visual angle |
D123 H100 V80.8 ±3° |
|
|
Camera focus method |
Fixed focus |
|
|
Video output |
MJPG YUY2 |
|
|
Maximum number of frames |
30 |
|
|
drive |
No drive |
|
|
Portrait resolution |
4160x3120(MAX) |
|
|
Microphone parameters (Optional) |
Microphone type |
Array microphones |
|
Number of digital mics |
8 |
|
|
sensitivity |
-26±1db |
|
|
Signal-to-noise ratio |
65db |
|
|
Pick-up distance |
10 meters |
|
|
Number of sample bits |
16KHZ |
|
|
Echo cancellation |
In the tank |
|
|
annex |
remote control |
Quantity: 1 pcs |
|
Power cord |
Quantity: 1.8 meters 1 strip as standard |
|
|
Touch pen |
Quantity: 1 stick |
|
|
Warranty card |
Quantity: 1 serving |
|
|
Certificate |
Quantity: 1 serving |
|
|
Wall mounts |
Quantity: 1 set |
|
